The Warrior Winches Samurai Range is our performance-focused range of electric winches engineered for serious recovery. Built around high-output motors, heavy-duty gearing and advanced braking technology, Samurai winches deliver the pulling power, control and durability needed when recovery conditions become demanding.
The Samurai 12,000lb 24V Synthetic Rope Winch delivers 12,000lb (5,443kg) of rated line pull from a high-output 24V motor, combining serious recovery power with the handling benefits of synthetic rope. With 253:1 planetary gearing, an external brake and 25 metres of 11mm synthetic rope, it is built to provide dependable performance when the terrain gets tough.
12,000lb of Serious Recovery Power. With 12,000lb (5,443kg) of rated line pull, the Samurai 12,000lb is built for demanding 4x4 recovery where substantial pulling power is required. It gives you the capability to tackle heavy vehicles, difficult terrain and challenging recovery situations.
24V Power for Faster Loaded Recovery. The 8.0hp / 6.0kW 24V motor delivers strong performance throughout the pull, with a line speed of 5.2m/min at the full 12,000lb rated load. The 24V system also draws 250A at maximum rated load, helping deliver efficient performance under heavy recovery conditions.
Synthetic Rope for Easier Handling. The 11mm x 25m synthetic rope provides the reach you need for serious recovery while offering easier handling than traditional steel rope. Its lower weight makes the recovery line easier to position, deploy and manage around the vehicle.
External Braking for Controlled Recovery. The Samurai's external brake moves braking heat away from the drum, helping maintain controlled operation during demanding pulls. It also provides reliable load holding when the winch is under pressure.
253:1 Planetary Gearing for Heavy Recovery Loads. Heavy-duty 253:1 planetary gearing provides the mechanical advantage needed to turn the motor's output into controlled pulling power. Full-steel HRC50 gears are engineered for strength and durability when serious loads are involved.
Hawse Fairlead for Synthetic Rope. The aluminium hawse fairlead provides a smooth guiding surface for the synthetic rope as it enters and exits the drum. This compact setup works particularly well with synthetic rope and helps maintain controlled rope movement during recovery.
Built for Tough Off-Road Conditions. IP67 waterproof sealing helps protect the winch against dust and water ingress, making it well suited to the mud, dirt and wet conditions encountered during serious off-road recovery.
High-Performance Electrical Components. The 600A Silver Tip Contactor works with the high-output motor to provide dependable electrical performance, while the Silver Copper Motor with Copper Brush Holders is designed for durability and efficient operation during demanding winching.
Take Control from Where You Need It. The Samurai 12,000lb includes a 3.8m wired remote handset and an isolation switch is also supplied for convenient electrical control.
Serious Capability Without Unnecessary Rope Weight. With 12,000lb of pulling power, a 24V high-output motor and 25 metres of synthetic rope, the Samurai 12,000lb combines heavy-duty recovery capability with a rope system that is easier to handle and position.
Ready for Demanding 4x4 Recovery. Supplied with the Samurai winch, aluminium hawse fairlead, synthetic rope, heavy-duty battery leads, 3.8m wired remote, removable heavy-duty hook, isolation switch and stainless steel mounting hardware, this is a complete recovery winch package ready for installation.
The Warrior Winches Samurai 12,000lb 24V Synthetic Rope Winch combines 12,000lb pulling power, 24V performance, 253:1 planetary gearing, external braking and 25 metres of synthetic rope into a serious 4x4 recovery solution. The Samurai range is backed by a 5-year warranty, subject to Warrior Winches' warranty terms and product registration requirements.
