The Warrior 24V DC Winch Hoist is designed for lifting applications where strong pulling power and controlled operation are essential. Its 24V electrical system delivers powered lifting performance without requiring a conventional mains supply, making it an option for suitable installations with a compatible 24V power source.
With a maximum rated line pull of 2,600lb (1,180kg), 28 metres of steel rope and a 24V series-wound motor, this model combines substantial lifting capacity with practical control and protection features. An automatic mechanical brake, overload protection and a sealed control box help support dependable operation when the hoist is installed and used correctly.
Handle Loads of Up to 1,180kg. The Warrior 24V DC Winch Hoist provides a maximum rated line pull of 2,600lb (1,180kg) on the first layer of rope.
Lift with the Reach of 28 Metres of Steel Rope. A 28-metre length of 8.1mm steel rope gives you flexibility when positioning loads at different heights. The steel rope is wound onto a robust drum, providing useful reach for lifting arrangements where a shorter cable could limit your setup.
Benefit from a High-Output 24V Motor. The series-wound DC motor delivers 6.1kW of input power and 3.1kW of output power. Compared with the 12V version, the 24V system draws less current at equivalent listed loads, which can be beneficial when planning a compatible electrical installation. At no load, the listed lifting speed is up to 8.4m/min, with speed decreasing as the load increases.
Keep Lifting Controls Within Reach. The supplied wired hand remote allows you to operate the hoist from a convenient position, while its integrated emergency stop provides a direct way to stop operation when needed.
Help Protect the Load with an Automatic Cone Brake. The automatic mechanical brake is designed to hold the rated load when the motor stops, including in the event of power loss. This supports controlled lifting and helps limit unwanted load movement, but correct installation, load assessment and safe operating procedures remain essential.
Reduce Routine Gear Maintenance. The three-stage planetary gear train uses permanent grease lubrication, helping reduce the need for regular gear lubrication. Its clutchless operation also keeps the operating setup straightforward, so you can concentrate on positioning and managing the load.
Add Protection with an IP68-Rated Control Box. The sealed control box carries an IP68 rating to help protect the electrical components against dust and water ingress under the specified test conditions.
Overload Protection for Greater Equipment Confidence. Integrated overload protection helps protect the hoist against excessive loading, supporting safer use and helping reduce the risk of equipment damage.
Designed with Recognised Hoist Standards in Mind. The hoist conforms to parts of BS EN 14492-1.
A Complete 24V Lifting Package. Supplied with the DC winch hoist, steel rope, heavy-duty hook, wired remote handset with emergency stop, watertight contactor and mounting hardware, this model provides the main components needed for a suitable installation. Before use, confirm that the 24V power supply, mounting structure and complete lifting arrangement are appropriate for the intended task.
For applications requiring a compatible 24V power supply, the Warrior 24V DC Winch Hoist combines a 1,180kg maximum rated line pull with extended steel rope reach and integrated load-control features. It comes with a 12-month warranty.
